Coated Duplex Board with Grey Back (C1S)

Aug 08, 2017

Basic Info

  • Model NO.: RVT-DC

  • Material: Recyclable

  • Brand: Dragon Plus

  • thick: 12PT, 0.305 mm, 14PT, 0.356 mm, 16PT, 0.406 mm, 18PT, 0.456 mm, 20PT, 0.508 mm

  • Packaging: High Strength Plywood Pallet

  • MOQ: 1*20′ft FCL

  • Trademark: Dragon Plus

  • Specification: Size ≥ 55*70cm or width ≥ 50cm

  • HS Code: 4810920000

  • Usage: Gifts, Cosmetics, Food, Shoes, Electronics, Beverage

  • Type: Clay Coated Dulex Board with GreyBack

  • Specifications: 700X1000mm or Other

  • Business Type: Manufacturer

  • Delivery: 15 Days Against Receiving Deposit or L/C

  • Quality Feature: Consistent with High Stiffness

  • Transport Package: Ream or Roll

  • Origin: China


Product Description

Our Duplex board could be perfectly used for blistering.

1. Product range: 230-450GSM available in different quality grade.

2. Size: Sheets and reels are both available, 700X100, 0mm and any special sizes available.
3. Features: Standard weight, high-standard stiffness, even thickness, coated surface, good smoothness and PPS, etc.
4. Typical applications: Widely used in packaging and printing like Shoe boxes, wine packages, cigarette middle packages, matchboxes, toothpaste boxes, cosmetics outer packaging, or whatever packaging the item may be suitable for.
5. Material: Imported waste paper and imported pulp.
6. Chemicals used: As per different requirement for said article.

We mainly produce Duplex board with grey back(DC), Triplex board with white back(TR), Virgin White-top Liner, Ivory board(IV), and other packing and printing papers.

Technical Specifications:

Document NameStandard for Duplex Board with Grey BackDocument No.QC806002
Issue Date5th Jan, 2014VersionL
TECHNICAL DATA FOR DUPLEX BOARD WITH GREY BACK
ItemUnitTest
Method		Grade AAGrade A
Basis WeightG/M2 ISO 536:1995            230           250               300           350 ±  3%400           450
Density≤300 G/M2 G/M3 ISO 534:19980.820.83
>300 G/M20.800.81
Brightness  (face)     ≥%ISO2470:199994.092.0
Smoothness      ≥ sISO5627:1995200.0150.0
PPS Roughness      ≤ μmISO8791-4:19921.802.00
Printing Gloss      ≥ %GB/T 1203290.088.0
Oil Absorbance
(K&N Value)		 %GB/T 1291115~28
Resistance to picking
( Middle Viscosity) ≥		m/sISO 3783:19801.501.40
Cobb
Water absorptiveness		face    ≤G/M2 ISO 535:199150
back    ≤120
Stiffness
CD
≥		230 G/M2mN·mISO2493:19922.502.30
250 G/M23.203.00
300 G/M25.405.20
350 G/M27.907.60
400 G/M211.0010.60
450 G/M215.2014.50
Dust
(Spot)
≤		0.2~1.0mm2 each/m2 GB/T 15411012
>1.0~2.0mm2 00
 >2.0mm2 00
Moisture≤300 G/M2 %ISO 287:19917.0±1.0
>300 G/M27.5±1.0
*Test conditions: ISO 554 - 1976 (23 ± 1 °C / 50 ± 2 %)
*MD= Machine Direction CD= Cross Direction
